S1613 drilling diamond composite sheet
Video
The 1613 PDC flat cutter is a high-performance polycrystalline diamond compact. It consists of a 16mm diamond layer and cemented carbide substrate, manufactured via high temperature and high pressure sintering process. As a core cutting component for PDC drill bits, it features a flat cutting structure that concentrates cutting force and delivers outstanding rock shearing efficiency. This cutter works reliably in medium-hard to hard complex formations, effectively boosting drilling speed and extending overall bit service life. It is a reliable choice for oil & gas well drilling, water well drilling, geological exploration and other drilling operations.
Parameter Table
|
Model NO. |
S1613 |
Length |
Standard |
|
Type |
PDC Cutter/Insert/Button |
Material |
Tungsten Carbide |
|
Usage |
Well Drilling, Oilfield,Gas Field,Mining Industry,Construction |
Wear Resistance |
Super High |
|
Thermal Stability |
750℃,800℃,850℃,900℃ |
Production Process |
Hthp Sintering |
|
Diamond Grade |
PCD |
Substrate Material |
Tungsten Carbide |
|
Total Height |
5~34 |
Tolerance |
±0.02mm |
|
Impact Toughness |
Excellent |
Certification |
ISO 9001 |
|
Shape |
Round |
Matched Drill Bit |
PDC Drill Bits, Core Bits, Tricone Bits, Drill Pipes (We also offer custom drill bit manufacturing) |
|
MOQ |
100PCS |
Specification |
1613 |
|
Transport Package |
Customized, Carton/Wooden Case |
Origin |
China |
|
Trademark |
Ninestones |
Production Capacity |
10000pieces/Year |
Applicable Strata
- Medium-hard formations: Tight sandstone, limestone, dolomite (compressive strength: 15,000–25,000 psi)
- Hard formations: Granite, basalt (compressive strength: 25,000–30,000 psi)
- Mixed interbedded formations: Alternating soft and hard rock layers with abrasive particles
- Highly abrasive formations: Strata containing quartz, chert and other hard minerals
Core Product Advantages
Powerful cutting performance
With 16mm large diameter design, it owns larger cutting area and higher rock breaking efficiency. Its cutting capacity is about 20% higher than conventional 1313 cutters.
Excellent wear resistance
Equipped with thickened diamond layer, the abrasion ratio exceeds 40. Its service life is prolonged by over 30% when working in highly abrasive formations.
Superior impact resistance
The diamond layer and carbide substrate are tightly combined with high bonding strength. It can resist strong impact and greatly reduce the risk of cutter chipping and breakage.
Good thermal stability
Adopted customized diamond formula, the cutter resists high temperature and thermal cracking, and adapts to harsh high temperature and high pressure downhole environment.
Stable operating performance
The flat structure ensures even force distribution and stable torque during drilling, bringing smoother and more controllable operation.
Cost-effective
Long service life reduces frequent replacement and tripping operations, cutting down the comprehensive operating cost for large-scale drilling projects.
Precise Size Specifications
Full product range with multiple specifications available, including standard models of 13mm, 19mm and 22mm, as well as thickened and heightened DE series. All products are manufactured with a strict tolerance of ±0.02mm, ensuring tight fitting installation, stable operation and no vibration.
Material and Core Technology
Adopts high-density premium cemented carbide substrate combined with high-purity PCD polycrystalline diamond material. The substrate features high hardness while the diamond layer delivers outstanding wear resistance, improving product durability fundamentally.
Sintered under 5–6 GPa pressure and temperature above 1500℃. The two layers are integrated firmly without delamination or falling off in long-term use.
Processed by CNC grinding equipment to ensure strict dimensional tolerance and high surface finish. Optimized chamfer design disperses stress concentration effectively.
Application Field
Oil & Gas Drilling
Used as main cutting teeth and gauge teeth for PDC bits, suitable for directional wells and horizontal wells
Water well drilling
Ideal for medium and deep water wells in hard rock formations
Geological exploration
Core drilling and mineral resource exploration
Coal mining
Drilling for gas drainage holes and water detection holes in coal mines and surrounding rock
Geothermal drilling
Fits geothermal well construction, features high temperature resistance and wear resistance
Customized Service
- Custom dimensions: Adjust diameter, total height and diamond layer thickness to match special drill bit designs
- Custom chamfer: Provide 30°, 45°, 60° and other chamfer angles to meet different cutting demands
- Custom structure: Develop special tooth shape and chip removal groove for specific formations and drilling techniques
- Custom performance: Modify diamond formula and sintering process to enhance wear resistance, impact resistance or thermal stability as required
|
Cutter Model |
Diameter/mm |
Total |
Height of |
Chamfer of |
|
S0505 |
4.820 |
4.600 |
1.6 |
0.5 |
|
S0605 |
6.381 |
5.000 |
1.8 |
0.5 |
|
S0606 |
6.421 |
5.560 |
1.8 |
1.17 |
|
S0806 |
8.009 |
5.940 |
1.8 |
1.17 |
|
S0807 |
7.971 |
6.600 |
1.8 |
0.7 |
|
S0808 |
8.000 |
8.000 |
1.80 |
0.30 |
|
S1008 |
10.000 |
8.000 |
1.8 |
0.3 |
|
S1009 |
9.639 |
8.600 |
1.8 |
0.7 |
|
S1013 |
10.000 |
13.200 |
1.8 |
0.3 |
|
S1108 |
11.050 |
8.000 |
2 |
0.64 |
|
S1109 |
11.000 |
9.000 |
1.80 |
0.30 |
|
S1111 |
11.480 |
11.000 |
2.00 |
0.25 |
|
S1113 |
11.000 |
13.200 |
1.80 |
0.30 |
|
S1308 |
13.440 |
8.000 |
2.00 |
0.40 |
|
S1310 |
13.440 |
10.000 |
2.00 |
0.35 |
|
S1313 |
13.440 |
13.200 |
2 |
0.4 |
|
S1316 |
13.440 |
16.000 |
2 |
0.35 |
|
S1608 |
15.880 |
8.000 |
2.1 |
0.4 |
|
S1613 |
15.880 |
13.200 |
2.40 |
0.40 |
|
S1616 |
15.880 |
16.000 |
2.00 |
0.40 |
|
S1908 |
19.050 |
8.000 |
2.40 |
0.30 |
|
S1913 |
19.050 |
13.200 |
2.40 |
0.30 |
|
S1916 |
19.050 |
16.000 |
2.4 |
0.3 |
|
S2208 |
22.220 |
8.000 |
2.00 |
0.30 |
|
S2213 |
22.220 |
13.200 |
2.00 |
0.30 |
|
S2216 |
22.220 |
16.000 |
2.00 |
0.40 |
|
S2219 |
22.220 |
19.050 |
2.00 |
0.30 |
Customer Reviews
Drilling Team of Domestic Oil & Gas Company
We use 1613 PDC flat cutters for tight sandstone drilling. The penetration rate is much faster than the 1313 model we used before. The cutters last longer and we cut down tripping times a lot. It really helps us save operating cost.
Geological Exploration Company
These cutters perform great in granite formations. No chipping or falling off happened during operation. The quality and stability are beyond expectation. We will keep purchasing.
Directional Drilling Service Provider
We ordered customized chamfer 1613 cutters for our directional drill bits. The torque stays steady and directional control is accurate. The products fully meet our requirements for complex well construction.
Packaging
Each cutter is packed in individual shockproof plastic box. All goods are put into thick cartons filled with pearl cotton for extra protection against collision and damage during transit.
Delivery
Sample and bulk orders are acceptable. We support express, air freight and sea freight. Sufficient production capacity ensures stable lead time, safe and on-time delivery worldwide.
FAQ
-
Q：What is the difference between 1613 and 1313 PDC cutters?
A:The 1613 model has 16mm diameter, larger cutting size and stronger wear resistance, mainly for medium-hard and hard formations. The 1313 cutter is smaller in diameter with higher tooth density, more suitable for fast drilling in soft to medium-hard formations.
-
Q:What rock hardness can this cutter handle?
A:Standard version is applicable for formations with compressive strength from 15,000 psi to 25,000 psi. Custom thick diamond layer version can work in ultra-hard abrasive formations over 30,000 psi.
-
Q:What is the normal service life?
A:Under standard working conditions, the service life ranges from 800 to 1500 working hours. The actual lifespan is affected by formation hardness, abrasiveness and drilling parameters. We can customize high-wear-resistance version to extend service life for harsh working conditions.
-
Q:Can this cutter be used together with other PDC cutter models?
A:Yes. Many customers match 1613 cutters on bit shoulder and gauge area, and use 1308 or 1313 cutters on central area. Mixed collocation improves overall performance for complex formations.
-
Q:What is the shelf life of the product?
A:The shelf life is 12 months after delivery. Please store properly in dry environment and avoid violent impact and damp condition.
